WTL维拓晶振手表智能穿戴25MHz晶振2060 2*6mm圆柱2脚插件晶振厂
品牌：WTL 系列：WA2 封装：49SMD 3 pins 频率：4MHz/8MHz/16MHz 负载电容：18pF/20pF/18pF 调整频差：±20ppm/±30ppm/±20ppm 工作温度：-40~+85℃/-20~+70℃/-40~+85℃ 温度频差：±30ppm 标价：0.57
分享到
产品介绍
Frequency Range(MHz) | 4~6 | 6~10 | 10~30 | 30~50 |
Mode | AT/Fundamental | |||
Load Capacitance (CL) | 8pF, 10pF, 12pF or Specify | |||
Frequency Tolerance( at 25°C ) | ±5ppm ~ ±30ppm or specify | |||
Operating Temperature Range | -20~+70°C or Specify | |||
Frequency Stability Over Operating Temperature Range | ±10ppm ~ ±30ppm or specify | |||
Equivalent Series Resistance (ESR) max. | 150Ω | 100Ω | 80Ω | 60Ω |
Storage Temperature Range | -55~+125°C | |||
Shunt Capacitance( C 0 ) | 5.0 pF Max | |||
Drive Level (Typical) | 1 ~ 100 μW (10μW typical) | |||
Aging @25 °C 1st Year (Max) | ±5 ppm/year | |||
